Application Areas：
The crusher can crush wood, trunk, branches, stalks, bamboo poles, wood blocks, twigs, leaves, bark, bamboo branches, bamboo leaves, feed, chemical raw materials and other materials into sawdust or sawdust, and the materials after crushing are widely used in sawdust.
The double material wood crusher integrates the functions of blade cutting, high-speed air impact and collision, and can complete the micro material sorting and processing process at the same time. In the process of blade cutting and crushing, the rotor generates high-speed air flow, rotates with the cutting direction of the blade, and the materials accelerate in the air flow and impact repeatedly, so that the materials are subject to double crushing at the same time, accelerating the crushing rate of the materials.
1. The materials with uniform crushing can be fully and effectively coarse and fine crushed in the crushing chamber.
2. High output, low energy consumption, high efficiency, fine and uniform discharge.
3. When using the equipment, it has the advantages of low noise, no pollution, simple operation and convenient maintenance.
4. The utility model has the advantages of reasonable structure, convenient movement, automatic feeding, safety and reliability.
The double material wood crusher integrates the functions of blade cutting, high-speed air impact and collision, and can complete the micro material sorting and processing process at the same time. In the process of blade cutting and crushing, the rotor generates high-speed air flow, rotates with the cutting direction of the blade, and the materials accelerate in the air flow and impact repeatedly, so that the materials are subject to double crushing at the same time, accelerating the crushing rate of the materials.
Model | 400 | 500 | 600 | 700 |
Cutter head diametermm | 400 | 500 | 600 | 700 |
Number of blades | 4 | 4 | 4 | 6 |
Blade length mm | 100 | 130 | 150 | 200 |
Orifice diameter mm | 150×150 | 200×200 | 250×250 | 300×300 |
Spindle speed r / min | 2600 | 2600 | 2500 | 2600 |
Matched motor kw | 5.5-7.5 | 11 | 15 | 18.5-22 |
Matching diesel engine horsepower | 15 | 20 | 30 | 45 |
Output kg / h | 800-1000 | 1000-2000 | 2000-3000 | 3000-3500 |
