Application Areas:
disc chipper
Application Areas:
disc chipper
Wood chipper belongs to one of the wood processing equipment series. Widely used in textile, papermaking, pulping, wood-based panel and other industries in the production process of material preparation section. The main cutting materials of this machine are the small path wood after peeling, bamboo, board and felling residual materials.
1, wood chipper adopts low pressure or high voltage motor, large wood chipper has two kinds of pulley drive and direct drive; There are two ways of feeding water and tilting, and there are two ways of discharging material: upper discharging and lower discharging.
2, wood chipper compact structure, reasonable layout, easy installation, easy operation and maintenance, high production capacity; When cutting logs, the wood chip quality is high, and the length of the wood chip can be freely adjusted within the specified range, which is a new disk chipper.
3, the production of this series of wood chipper, users can choose their own models according to needs.
4, wood chipper by the base, cutter, feed port, cover, electric control system and other parts of the composition.
The wood is fed by the feed port. When the wood is in contact with the cutting blade, it is cut with the high-speed rotation of the cutting cutter. The cutting mechanism is a rotating drum, which is installed with a number of flying knives. There are a number of square holes on the outer edge of the drum, the qualified sheet material cut down through the mesh sieve hole, there is a bottom discharge, the large sheet will be cut again in the machine.
Model | Feed port mm | Yield (t/h) | Auxiliary motor | Diesel engine | Spindle speed | Cutter diameter | Alloy steel blade | Machine weight (kg) |
800 | 200*200 | 3-6 | 22kw | 30马力 | 480 | 800 | 4 | 750 |
950 | 260*260 | 5-8 | 30kw | 40马力 | 550 | 950 | 4 | 900 |
1100 | 330*330 | 6-9 | 45kw | 50马力 | 600 | 1100 | 4 | 1900 |
1210 | 380*380 | 8-10 | 75kw | 90马力 | 600 | 1210 | 4和6 两种 | 2600 |
1410 | 450*450 | 10-15 | 90kw | 100马力 | 600 | 1410 | 4和6 两种 | 3500 |
